Belt filter-automatic mesh belt screen changer/ extrusion melt filter
This kind of extrusion melt filter consists of the main body of the screen changer, the heating system , the cooling system , and the electrical controlling box.
and this kind of screen changer can be controlled by
-timer
-pressure sensor
- manual
1, when the material is virgin material , and the pressure is stablitity, under this case we can control the screen changer by the timer. for example, preset the screen changer interval is 2 hours , then we can make the timer off-state for two hours, and make it on for about 10 minutes.
2, when the material is very dirty, and the pressure of the material is fluctuate largely , and we require highly stablility, we can control the screen changer by the pressure sensor.
red color:heater
blue color: cooling system
when the Belt filter-automatic mesh belt screen changer/ extrusion melt filter
|
Type
|
Output
Kg/h
|
Size (mm)
|
Screen size
|
Heating tube
|
|
L1
|
L2
|
L3
|
Ф(mm)
|
cm2
|
V
|
W
|
|
ZB-ACB-50
|
30~85
|
150
|
165
|
540
|
Ф50
|
20
|
230/400
|
5200
|
|
ZB-ACB-70
|
75~200
|
160
|
170
|
560
|
Ф70
|
38
|
230/400
|
5400
|
|
ZB-ACB-90
|
100~290
|
170
|
185
|
580
|
Ф90
|
64
|
230/400
|
5800
|
|
ZB-ACB-100
|
130~350
|
180
|
215
|
605
|
Ф100
|
78
|
230/400
|
6200
|
|
ZB-ACB-120
|
190~500
|
185
|
230
|
645
|
Ф120
|
113
|
230/400
|
6500
|
|
ZB-ACB-150
|
350~800
|
200
|
265
|
700
|
Ф150
|
176
|
230/400
|
7200
|
|
ZB-ACB-180
|
450~1200
|
220
|
305
|
760
|
Ф180
|
254
|
230/400
|
8200
|
