Bidirectional stretching casting film screen changer

Introduction to Biaxial Stretch Casting Film Screen Changer

The production of biaxially stretched casting film and paper coated film has extremely high requirements for the sealing of the screen changer, and the production temperature is also high. Therefore, ordinary screen changers will basically encounter leakage or seepage problems. The BATTE casting film and coated film dedicated screen changer adopts a rigid sealing structure design, and at a high temperature of 340 ℃, the screen changer is produced normally without leakage or seepage.

casting film screen chagner

Working Principle of Casting Film Screen Changer

The bidirectional stretching casting film screen changer adopts a dual column and dual channel design, with internal heating, fast heating, and uniform temperature. During normal production, both filter screens work simultaneously. When replacing the filter screen, one filter screen works and the other filter screen is replaced. A material introduction and exhaust device is designed, which is controlled automatically or manually to achieve non-stop screen change, no material leakage, uninterrupted material flow, small material pressure fluctuation, little impact on production, and good continuity. Suitable for production under various working conditions with continuity requirements.

plastic film extrusion screen changer

Advantages of Film extrusion Screen Changer

The production of cast film generally adopts a dual column and dual station hydraulic non-stop screen changer. The advantage of using a dual column and dual station is to avoid long-term insulation and heating of the backup filtration station outside the screen changer body, aging of the raw materials in the screen plate, and a certain temperature difference between the temperature and production temperature, which will have a certain impact on production after screen replacement. For the production of PE/PP film, if it is to meet the requirements of continuous production without stopping, the dual column and dual station non-stop screen changer can also meet its needs, with a pressure of 35MPA, no impact on continuous production, and no material leakage. It is a very good choice.

hydraulic screen changer for plastic film extruder

Parameters of plastic film extrusion screen changer

1. Working temperature: ≤ 400 ℃;

2. Working pressure: ≤ 50MPa;

3. Pressure difference: ≤ 20MPa;

4. Applicable melt viscosity: 100~30000Pa. s;

5. Heating method: electric heating/heating medium heating.

screen changer for plastic extrusion
